The working principle of the 2GR twin-screw pump is to form a sealed space by rotating two screws in the pump body. As the screw rotates, the volume of these sealing spaces gradually increases and pushes the liquid from the suction end to the discharge end. Due to the rotation of the screw at equal speed, the flow of liquid outflow is uniform, ensuring the stability of the flow and the increase of pressure. It is suitable for a wide range of media, which can transport low viscosity or high viscosity media, and even media containing particles and corrosive substances. The twin-screw pump has self-priming ability and is suitable for various complex working conditions.
Parameter Range
Flow range | ~2000 m³/h |
| Maximum working pressure | 6 Mpa |
| Working viscosity | 2~10000 cst, Reduce the speed by up to 1x106 cst |
| Medium temperature | -20~+250℃ |
| Working medium | Such as heavy oil, residual oil, crude oil, asphalt, ink, paint, etc., and also suitable for various non lubricating media such as paraffin, latex, seawater, etc |
Technical Characteristics
‧Super Self-priming
‧Low noise, no agitation, no pulsation and smooth media transfer
‧High overall efficiency
‧Twin screw pumps of different configurations are suitable for a wide range of applications
‧It can realize the mixed transportation of gas and liquid
Application Areas
It is widely used in petroleum, chemical, metallurgy, electric power, shipping, pharmaceutical, food and other industries.
